Dongfeng 8.5 M³ Flammable Liquid Tanker Truck

Dongfeng 8.5 M³ Flammable Liquid Tanker Truck

Details
The Dongfeng 8.5 m³ Flammable Liquid Tanker Truck uses a single tank body with a specialist transfer pump, safety valve, bursting disc and bottom-valve warning system. A folding top rail, paired transfer hoses, tool storage and marked access points keep the operating layout compact and easy to inspect.
Category
Fuel Tanker Truck
Share to
Send Inquiry
Description
Technical Parameters

Hubei Ruitu Technology Co., Ltd. is one of the leading manufacturers and suppliers of dongfeng 8.5 m³ flammable liquid tanker truck in China. If you're going to wholesale the newest dongfeng 8.5 m³ flammable liquid tanker truck made in China, welcome to get quotation from our factory. All customized products and OEM products are with high quality and competitive price.



The Dongfeng 8.5 m³ Flammable Liquid Tanker Truck is configured for the controlled transport of ethanol, methanol and other compatible media within the stated density range. A 170 hp Yunnei engine, eight-speed Fast transmission and 3,800 mm wheelbase provide the chassis foundation. The cylindrical tank includes a dedicated 76/40 transfer pump, emergency bottom-valve alarm and pressure-relief arrangement with a bursting disc. Its moderate size helps operators reach industrial plants, chemical users and storage locations that are difficult for larger tankers. Guardrails, hose connections, extinguishers and a rear ladder are included around the working body for routine handling and inspection.

1
2
3
4
6



Our Advantages



  • Media-specific design: The source configuration identifies ethanol and methanol service rather than treating the body as a general fuel tank.
  • Pressure protection: A safety valve and bursting disc supplement the emergency bottom-valve arrangement.
  • Useful mid-range chassis: The 3,800 mm wheelbase and 170 hp engine balance access, payload and route flexibility.
  • Clear operating access: Hoses, rear ladder, folding rail and tool storage are positioned around a simple single-tank layout.



FAQ



Q: Which liquids are listed for the Dongfeng 8.5 m³ Flammable Liquid Tanker Truck?

A: The source identifies ethanol and methanol. Material compatibility and local transport classification must be confirmed for any other liquid.

Q: Why are nominal and published capacities different?

A: The production description uses an 8.5 m3 nominal configuration, while the published vehicle data lists 8.7 m3 total and 8.29 m3 effective volume.

Q: What pumping equipment is installed?

A: A 76/40 specialist pump is listed for liquid transfer, with the final connection standard agreed at order stage.

Q: Does the tank include pressure protection?

A: Yes. The described equipment includes a safety valve and a bursting-disc arrangement.

Q: What should a buyer confirm before production?

A: Confirm the exact medium, density, material compatibility, required connections, discharge method and destination-market rules.





Product Parameters



Specification

Reference Value

Vehicle model

CL5120GRY6

Chassis model

EQ1125SJ8CDCWXP

Nominal configuration

8.5 m3

Published tank volume

8.7 m3 total / 8.29 m3 effective

Permitted media

Ethanol or methanol; maximum medium density 790 kg/m3

Gross vehicle mass

11,950 kg

Rated payload

6,550 kg

Curb mass

5,205 kg

Overall dimensions

6,840 x 2,200 x 2,800 or 2,925 mm

Tank dimensions

4,700 x 1,600 mm (length x diameter)

Wheelbase

3,800 mm

Engine

Yunnei 170 hp configuration

Tyres

255/70R22.5 tubeless

Maximum speed

80 km/h
