Fuel Tank Trucks for Different Applications
Our China tank truck range includes configurations for gasoline and diesel transportation, as well as specialized liquid supply operations at oilfield sites. As a tank truck manufacturer and supplier, we offer available models covering effective tank volumes from 7.14 m³ to 25.15 m³, with different chassis configurations, tank structures, pumping systems and discharge equipment.
We offer fuel tanker truck configurations for two main operating requirements:
Fuel transportation: 8 m³ fuel truck and 20 m³ oil transport tanker for gasoline and diesel transportation.
Oilfield liquid supply: 28 m³ and 32 m³ liquid supply trucks for well-site liquid transportation, well servicing and related field operations.
The 28 m³ configuration is specified for well-site operating liquids, including water purifying agents and water-reducing agents, while the 32 m³ configuration is designed for well-servicing liquid supply. These models have different applicable media and should be selected according to the actual liquid properties.
-
Dongfeng 13.4 M³ Aircraft Fuel Refueling TruckThe Dongfeng 13.4 m³ Aircraft Fuel Refueling Truck is a medium-heavy aviation-fuel vehicle built around the DFH1180EX9 chassis and an air-suspended rear axle. Its published reference data combines...view more
-
Dongfeng 8.5 M³ Aviation Aircraft Refueling TruckThe Dongfeng 8.5 m³ Aviation Aircraft Refueling Truck balances useful aviation-fuel capacity with a 6.9 m reference vehicle length for regional airports, flight schools and distributed...view more
-
Dongfeng 4.85 M³ Compact Aircraft Refueling TruckThe Dongfeng 4.85 m³ Compact Aircraft Refueling Truck is a manoeuvrable aviation-fuel unit for smaller aprons, flight-training centres and remote airfields. Model CL5070GJYL6 has a 5,940 mm...view more
-
45000 L Aircraft Refueling TruckThe 45,000 L Aircraft Refueller Semi-Trailer is intended for high-volume aviation-fuel operations where trailer capacity and pressure-fuelling equipment are combined in one dedicated package. Its...view more
-
30000 L Heavy-Duty Aircraft Refueling TruckThe 30,000 L Heavy-Duty Aircraft Refueling Truck is a large-capacity mobile fuelling platform for operators that need fewer depot returns during demanding apron schedules. The reference...view more
-
20000 L Aircraft Refueling TruckThe 20,000 L Aircraft Refueling Truck is configured for high-volume apron fuel transfer where controlled delivery, filtration and metering must be coordinated from one mobile platform. Its...view more
-
Shacman 32 M³ Liquid Supply TruckThe Shacman 32 m³Liquid Supply Truck Truck uses a baffled carbon-steel tank and a high-capacity transfer line. Two manholes, an 80/60 pump, four-inch piping and a three-inch outlet provide a...view more
-
FAW 25 M³Fuel Tank TruckThe FAW 25 m³Fuel Tank Truck combines a 5182 aluminum inner tank, 80 mm insulation and a stainless outer cladding. Two tank openings, an 80/60 pump and aluminum transfer fittings provide a clean,...view more
-
FAW 8 M³ Fuel TruckThe FAW 8 m³Fuel Truck combines a single-compartment tank with one Euro manhole, gear pump and complete lower-loading controls. Folding rails, a non-slip top walkway, hoses, extinguishers and a...view more
-
HOWO 20 M³ Oil Transport Tanker TruckThe HOWO 20 m³ Oil Transport Tanker Truck uses a single-compartment Q235 tank with two manholes and pumped transfer. Its lower-loading station combines emergency shut-off, vapour return,...view more
-
HOWO 28 M³ Fuel Tanker TruckThe HOWO 28 m³fuel tanker truck uses a baffled Q235 tank with two access openings and an 80/60 pump. Four-inch main piping feeds a three-inch outlet, while the 8x4 chassis provides the carrying...view more
-
HOWO 25m3 Fuel TankerThe HOWO 25 m3 Fuel Tanker uses aluminum for the tank, guards and storage fittings. Two manholes, an 80/60 pump and a complete lower-loading package are installed around a single compartment, with...view more
Tank Truck Specifications and Configurations
The following specifications identify four available heavy-duty tank truck configurations. Nominal capacity, total tank volume and effective volume are listed separately because they are not interchangeable.
8 m³ FAW Fuel Tanker Truck
| Specification | Value |
|---|---|
| Vehicle model | CLQ5091GJY6CAQ |
| Chassis model | CA1091P40K61L2BE6A84 |
| Total tank volume | 7.5 m³ |
| Effective tank volume | 7.14 m³ |
| Applicable media | Gasoline / Diesel |
| Maximum media density | 700 kg/m³ |
| Tank structure | Single compartment |
| Tank material | Q235 carbon steel |
| Gross vehicle weight | 9,100 kg |
| Rated payload | 5,000 kg |
| Curb weight | 3,905 kg |
| Overall dimensions | 6,280 × 2,200 × 2,800 mm |
| Tank dimensions | 4,000 × 1,850 × 1,250 mm |
| Wheelbase | 3,600 mm |
| Engine | CA4DB1-14E68, 100 kW / 140 hp |
| Transmission | WLY 6-speed |
| Tires | 7.50R16LT 16PR |
| Maximum speed | 79 km/h |
20 m³ Oil Transport Tanker Truck
| Specification | Value |
|---|---|
| Vehicle model | CL5262GYYZ6 |
| Chassis model | ZZ1267N56CGF1K |
| Nominal capacity | Approx. 20 m³ |
| Total tank volume | 19.7 m³ |
| Effective volume | 19.46 m³ |
| Maximum media density | 750 kg/m³ |
| Tank structure | Single compartment |
| Tank material | Q235 carbon steel |
| Tank shell thickness | 5 mm |
| Head thickness | 5.75 mm |
| Gross vehicle weight | 25,500 kg |
| Rated payload | 14,600 / 14,665 kg (published configurations) |
| Curb weight | 10,705 kg |
| Overall dimensions | 10,000 × 2,500 × 3,230 mm |
| Tank dimensions | 6,950 × 2,300 × 1,500 mm |
| Engine | MC07H.35-60, 257 kW / 350 hp |
| Transmission | HW13709XSTC2, 9-speed |
| Maximum speed | 80 km/h |
28 m³ Oilfield Liquid Supply Tank Truck
| Specification | Value |
|---|---|
| Vehicle model | CLW5311TGYZ6 |
| Chassis model | ZZ1317N466GF1 |
| Production description capacity | Approx. 27.5 m³ |
| Total tank volume | 26.4 m³ |
| Effective volume | 25.15 m³ |
| Applicable media | Well-site operating liquids, water purifying agents and water-reducing agents |
| Maximum media density | 640 kg/m³ |
| Tank material | Q235 carbon steel |
| Tank shell thickness | 5 mm |
| Head thickness | 5.5 mm |
| Baffle thickness | 4 mm |
| Gross vehicle weight | 31,000 kg |
| Rated payload | 16,100 / 16,165 kg (published configurations) |
| Curb weight | 14,705 kg |
| Overall dimensions | 11,870 × 2,550 × 3,430 mm |
| Tank dimensions | 8,900 × 2,300 × 1,600 mm |
| Engine | MC07H.35-60, 257 kW / 350 hp |
| Maximum speed | 89 km/h |
32 m³ Oilfield Liquid Supply Tank Truck
| Specification | Value |
|---|---|
| Vehicle model | CL5310TGY6BWG |
| Chassis model | SX1319MC6Z1 |
| Production description capacity | Approx. 32 m³ |
| Total tank volume | 26.1 m³ |
| Effective volume | 24.87 m³ |
| Application | Well-servicing liquid supply |
| Tank material | Q235 carbon steel |
| Tank shell thickness | 5 mm |
| Head thickness | 5.5 mm |
| Baffle thickness | 4 mm |
| Gross vehicle weight | 31,000 kg |
| Rated payload | 15,000–15,665 kg (configuration dependent) |
| Curb weight | 15,205 / 15,805 kg (published configurations) |
| Overall dimensions | 11,760 × 2,550 × 3,480 mm |
| Tank dimensions | 8,800 × 2,500 × 1,730 mm |
| Wheelbase | 1,800 + 4,575 + 1,400 mm |
| Engine | WP10H375E62, 276 kW / 375 hp |
| Transmission | Fast 12JSD200TA-B, 12-speed |
Tank Truck Pumping, Loading and Unloading Equipment
Different tank truck models have different equipment configurations for fuel transportation and oilfield liquid supply.
| Model | Published equipment and configuration |
|---|---|
| 8 m³ fuel truck | Gear pump, bottom loading control, vapor recovery, overflow monitoring and emergency bottom valve |
| 20 m³ oil transport tanker | 80/60 pump, bottom loading and discharge, vapor recovery, overflow sensing and static electricity control |
| 28 m³ liquid supply truck | 80/60 pump, 4-inch main pipeline, 3-inch outlet and tank baffles |
| 32 m³ liquid supply truck | 80/60 pump, 4-inch pipeline and 3-inch outlet; pump supports suction and delivery |
For mobile fuel dispensing operations, the 8 m³ fuel truck offers the following optional equipment:
- High-flow fuel dispenser.
- 15 m automatic hose reel.
- Fuel dispensing nozzle.
The automatic hose reel is an optional component. It does not indicate that the complete loading and unloading process is fully automated.
Custom Tank Truck Configurations and OEM Options
As part of our tank truck customization service, we offer the following documented configuration options:
Fuel dispensing equipment: The 8 m³ fuel truck can be equipped with an optional high-flow fuel dispenser, 15 m automatic hose reel and dispensing nozzle.
Tank compartments: The 8 m³ model has a documented single-to-double-compartment conversion option, subject to engineering evaluation.
Compartment arrangement: The 20 m³ model can be evaluated for alternative compartment arrangements, subject to tank volume, load distribution and vehicle approval requirements.
Tank material: For the 28 m³ oilfield liquid supply model, alternative materials can be evaluated for corrosive liquids based on chemical composition, concentration, operating temperature and cleaning conditions.
Non-standard tank structures and equipment combinations are assessed individually according to the intended application.
Tank Truck Manufacturing and Factory Supply Support
Our special-purpose vehicle manufacturing operations cover material cutting, tank forming, bending, welding, painting, vehicle assembly and quality inspection.
Our production equipment includes:
- CNC fiber laser cutting machines.
- Robotic welding workstations.
- CNC bending machines.
- Automatic shot-blasting equipment.
- Vehicle water-testing lines.
Our company reports cumulative production and sales of 10,000 special-purpose vehicles across its overall product range during the past three years. This figure covers the company's broader vehicle business, not tank trucks alone.
As a China-based special-purpose vehicle supplier, we also provide OEM/ODM cooperation, international trade support, technical assistance, spare-parts supply and maintenance guidance.
Available trade terms include FOB, EXW, CFR, CIF, DAP and DDP, subject to the specific order arrangement.
Request a Tank Truck Manufacturer Quotation
Send us your required tank capacity, transport medium, destination country and preferred vehicle configuration to request a suitable tank truck proposal.
You can also send an existing vehicle specification sheet, reference photos or estimated order quantity. Our team can review your requirements and provide a corresponding vehicle configuration and quotation.
