Hubei Ruitu Technology Co., Ltd. is one of the leading manufacturers and suppliers of 18m³ mobile waste compactor station in China. If you're going to wholesale the newest 18m³ mobile waste compactor station made in China, welcome to get quotation from our factory. All customized products and OEM products are with high quality and competitive price.
The 18m³ Mobile Waste Compactor Station is designed for the collection, compaction, and transfer of municipal solid waste in locations with high waste generation volumes. It is suitable for residential developments, commercial centers, industrial parks, markets, and waste transfer stations where efficient waste handling is required.
The unit features an 18m³ compaction chamber and a hydraulic compaction system that reduces waste volume and increases payload efficiency during transportation. Its enclosed structure helps contain waste, control odors, and minimize leachate leakage, supporting cleaner and more organized waste management operations.
Designed for flexible deployment, the station can be used with hooklift trucks or dedicated transfer vehicles for container transportation. Compared with fixed waste compaction facilities, the mobile design offers greater flexibility for installation, relocation, and changing operational requirements, making it suitable for municipal sanitation services and large-scale waste collection projects.
Our Advantages
1. The waste compactor station is developed by our company based on the market demand for domestic sanitation equipment and waste transfer modes.
2. The waste compactor station is a waste compression treatment device independently developed by our company with advanced technology and processes. It is mainly used for the collection and transfer of domestic waste from urban streets, commercial areas, residential factories, schools, and hospitals.
3. This equipment is mainly suitable for waste collection methods involving feeding by manual carts and small motor vehicles of 1.5 tons or less (with a width not exceeding 1.8 meters).
FAQ
Product parameters
| Item | Unit | Model & Parameter |
Product Model
| /
| CLZNY18-A
|
Overall Dimensions (L×W×H)
| mm
| 6400×2480×2530 (±50)
|
Theoretical Waste Processing Capacity
| t/h
| 18
|
Motor Power
| kW
| 7.5
|
System Max. Pressure
| MPa
| 21
|
Max. Compression Force
| kN
| 360
|
Max. Lifting Force of Feeding Mechanism
| t
| 2
|
Waste Bin Volume
| m³
| 18
|
Compression Chamber Volume
| m³
| 4.5
|
Compaction Cavity Volume
| m³
| 1.7
|
Compaction Density
| t/m³
| ≥0.75
|
No-Load Compression Cycle Time
| S
| ≤35
|
Tipper Cycle Time
| S
| ≤30
|
Tipper Volume
| m³
| ≥3.5
|
Guide Rail Width
| mm
| 1060
|
Hook Center Height
| mm
| 1570 (0,+10)
|
Power Supply
| /
| 380V/50Hz/10kW
|
