HOWO Expandable Command And Communication Vehicle

HOWO Expandable Command And Communication Vehicle

Details
The HOWO Expandable Command and Communication Vehicle brings command, communications, meetings, and technical coordination directly to an incident site.
Category
Command Truck
Share to
Send Inquiry
Description
Technical Parameters

Hubei Ruitu Technology Co., Ltd. is one of the leading manufacturers and suppliers of howo expandable command and communication vehicle in China. If you're going to wholesale the newest howo expandable command and communication vehicle made in China, welcome to get quotation from our factory. All customized products and OEM products are with high quality and competitive price.



The HOWO Expandable Command and Communication Vehicle uses a 4x2 chassis, expandable body, automatic leveling supports, and separated power, technical, and meeting zones. A 25 kVA generator, UPS, centralized distribution, grounding, surge protection, cable reels, warning lights, and scene lighting support field deployment. Radio, satellite, video, computing, display, and conferencing equipment can be integrated after the operator count, rack loads, interfaces, cooling demand, and local communication requirements are confirmed.

e09641a93a6b500778ac06c226740f6001
58e0e5f93816a1d56b9c20429970605001
61deded19d51e5132a44801813fff42001
97ae45359f90ef23091286dc8ecc7c3001
a69c0872a08af3845f7926889137d5f001



Our Advantages



  • Expandable working volume: The double-side expansion system increases usable floor area for meetings and operator stations without requiring a separate shelter.
  • Independent field power: Generator, UPS, centralized distribution, grounding, and surge protection form a practical power chain for sensitive command equipment.
  • Planned functional zoning: Power, technical work, and meeting activities can be separated so equipment maintenance does not interrupt command discussions.
  • Integration-ready body: Equipment racks, cable routes, displays, communication terminals, mast interfaces, and workstations can be engineered around the customer's system list.



FAQ



Q: What information is required before ordering the HOWO Expandable Command and Communication Vehicle?

A: Provide the number of operators, equipment list, rack dimensions and weight, communication links, antenna or mast requirements, display plan, expected deployment time, and local power standard. RUITU uses these inputs to prepare the layout, load distribution, cooling plan, and interface schedule.

Q: Can the vehicle operate where there is no shore power?

A: Yes. The listed configuration includes a 25 kVA silent generator, UPS, and onboard distribution system. The final endurance depends on the installed equipment load and fuel plan, so the power balance should be confirmed against the customer's actual devices.

Q: How is the body stabilized when the side sections are extended?

A: The specification includes four-point automatic leveling supports with manual backup operation. The vehicle must be parked on suitable ground, leveled, and secured before the expansion system is operated.

Q: Can customer-supplied radio and IT equipment be installed?

A: Yes, after interface review. RUITU can reserve rack space, power circuits, network paths, grounding points, and cable entries, while the customer or nominated integrator remains responsible for licensed frequencies, encryption, and country-specific approvals.

Q: What should be checked during acceptance?

A: Acceptance should cover driving performance, axle loads, expansion and leveling cycles, generator and UPS operation, circuit protection, grounding, air-conditioning under equipment load, communication links, lighting, water ingress, and access for routine maintenance.





Product Parameters



Parameter

Specification

Chassis Model

ZZ5187XXYN711GF1

Chassis Brand

HOWO

Drive Type

4x2

Overall Dimensions

10630 x 2550 x 3980 mm

Wheelbase

5800 mm

Engine Model

MC07.31-60

Rated Engine Power

228 kW

Engine Displacement

6.87 L

Emission Standard

China VI, GB17691-2018

Maximum Speed

89 km/h

Silent Generator

25 kVA rated, 30 kVA standby

Cable Reel

Electric reel with at least 40 m cable
